HDTR-800E
? Fully Compliant with DVB-T2 and DVB-T
? Support MEPG-4 AVC(H.264) MP/HP@L4.1 Support MEPG-2 MP@HL/ML
? HE AAC5.1, HE AAC+, DD, DD+ (Dolby is optional)
? Multi Bandwidth: 6M 7M & 8M
? Supports 64QAM, 16QAM and QPSK (4QAM) sub-carriers
? Video decoding and output: 1080p/1080i/720p
? Analog Video output: PAL/NTSC
? Conversion between SD programs and HD programs
? USB2.0 supported for upgrade, PVR and time shifting
? SupportParental Control,Teletext,Subtitle
? Support MEPG-4 AVC(H.264) MP/HP@L4.1 Support MEPG-2 MP@HL/ML
? HE AAC5.1, HE AAC+, DD, DD+ (Dolby is optional)
? Multi Bandwidth: 6M 7M & 8M
? Supports 64QAM, 16QAM and QPSK (4QAM) sub-carriers
? Video decoding and output: 1080p/1080i/720p
? Analog Video output: PAL/NTSC
? Conversion between SD programs and HD programs
? USB2.0 supported for upgrade, PVR and time shifting
? SupportParental Control,Teletext,Subtitle
-
• Aspect ratio: 4:3/16:9,By Pan & Scan and Letter Box conversion
• Electronic program guide (EPG)
• Software upgrade (OAD or USB)
• 32 bits true color OSD
• Program editor
• Support Favorite GroupCPU and Memory CPU Mstart 7T00 DDR2 DDR2 512Mbit(64MByte) Flash 32Mbit(4MByte) Tuner Tuner R836 & MXL608 Connector Type RF In/ANT In(IEC-Female),AV,COAXIAL,HDMI,RJ_45,USB Input Frequency (UHF)470∽866MHz, (VHF)170∽231MHz Bandwidth 6, 7, 8MHz Signal Input Level -78∽-20dBm Input Impedance 75 Ohm Active Antenna 5V(On/Off), Imax=100mA Demodulation Scheme QPSK, 16-QAM, 64-QAM, 256-QAM FFT 1K, 2K, 4K, 8K, 16K, 32K FECE mode 1/2, 2/3, 3/4, 3/5, 4/5, 5/6 Guard Interval 1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256 Software Function OS ECOS EPG Fully support to 7 days Electronic Program Guide(EPG) Video Decoding MPEG1, MPEG2, MPEG4, H264, VC-1, MOTION JPEG, MPG, MP4 Video Format avi, mp4, mkv, mov, dat, flv, mpg, vob, 3gp, ts Audio Decoding MPEG-1/2/3/4, wma Audio Format mp3, wma, agg Picture Format JPEG, BMP, PNG Video Resolution 480i, 480P, 576i, 576P, 720P, 1080i, 1080P Video Aspect Ratio 4:3(LB/SCAN), 16:9(LB/FIT) Analog Video System PAL, NTSC, SECAM OSD Language nine kinds of language LCN Sort Support Logic Channel Number(LCN) Teletext VBI insertion for Teletext,CC and WSS Time Shift Support Time Shift Hardware Interface Video Output RCA(CVBS, L/R), HDMI Interface USB Interface 1*USB2.0 Power supply DC5V 1A 5WMax Package Product size 220*140*40mm Applications Internet ,USB WiFi support( M7601 chipset wifi),Megogo, IPTV Support USB import IPTV programs, as txt,xml,m3u files
